Item
Specification
Structure 12" 19 lb. beams, Carbon Steel, Fully Welded
Dimensions
Available in 5 yd., 7 yd., 12 yd., 15 yd., and 20 yd.
Hydraulic System
12 gpm @ 2000 psi or 2 gpm @ 3200 psi
Control System
3 - Way, 3 Control Valve Manifold with Optional Remote Control
Power Unit
15 hp. Single Cylinder Diesel or Gas Motor with Safety Switches or 2hp Electric Unit
Axles
2 - 10,000 lbs. Heavy Duty Dully with Disc Brakes
Suspension
Tandem heavy Duty 10,000 to 15,000 lbs.
Brake System
Electric over Hydraulic, Self-Charging with Safety Brake Away
Lift System
2 - 4" Hydraulic Cylinders, Double Acting or Singe Point Scissors
Wheels
8 - D/W 16 x 6 x 865 3,000 lbs. (8 studs)
Safety Equipment
DOT Reflectors,DOT Bumper, Security Trailer Chains, Brake-Away Brake System
Options
Goose-Neck, Pintle or Ball Hitch, Hydraulic Operated Door, Raising and Latching

Click Here to download printable Dump Trailer Specifications
