Certified for 29" of Hg

Item
Specification
Structure Carbon Steel with All In and Out Seams Fully Welded
Dimensions (25 yd)
23 ft. L x 8 ft. W x 6.5 ft. H
Dimensions (30 yd)
23 ft. L x 8 ft. W x 7.5 ft. H
Shell
1/4" Carbon Steel
Front Wall
1/4" A-36 with 6x2 Support Tubings
Door
1/4" A-36 with 3" Sq. Tubing Frame
Wall Supports
Formed Channel at 33.5" Intervals
Roof

1/4" Plate with 4x3 Tubing at 33.5" Intervals

Floor
1/4" Plate with 3" 4.1 Channel at 16" Intervals
Bottom Rails
6x2x1/4"
Door Seal
T-Extruded Neoprene Gasket with 12 Point Chain System
Optl. Door Securing System
Steel Latching Arms operated via Ratchet Binder System
Included Accessories
1-20" Manhole Cover on the Roof, 2-8"Pipe Flanges
Optional Accessories
Up to 5 Manhole Covers on the Roof, Various Pipe Fittings
Testing
Containers Tested to Maximum Capacity with an Optional Hydrotest to 10 PSI

Click Here to download printable Vacuum Container specifications
